WEBER Classic 4.0M
Features
Electrohydraulic 2 post lift for cars and vans
- Sturdy cover plate as a collision protection between the columns
- torsion-resistant column profiles
- Column covers on both columns
- manual release of the mechanical safety pawls
- electronic stroke limitation
- Foot deflector as anti-trap
- easy handling by 24 volt safety button control (deadman control)
- low undershoot height
- Door protection rubbers on both columns
- large passage width, also suitable for vans
- conically fine toothed support arm lock, automatically and manually unlocked
- asymmetric support arms for large door opening angles
- Maintenance and wear-resistant, thus low follow-up costs
- powder coated surfaces
- the essential components of the stage are pre-assembled
Technical specifications
| Load capacity | 4000 kg |
|---|---|
| pad height | 110 mm |
| Lifting height max | 1940 mm |
| Crossover height | 50 mm |
| colum height | 2830 mm |
| Required room height | 3100 mm |
| column spacing | 2830 mm |
| clearance width | 2580 mm |
| installation width | 3560 mm |
| length of long arm | 900-1400 mm |
| length short arm | 620-880 mm |
| Electrical connection | 230 V / 1 Ph / 50 Hz |
| engine power | 2,2 kW |
| Lifting time | 55 Sec. |
| mass | 585 kg |
| Color support arms | red Ral 3020 |
| Color pillar | black Ral 9017 |
Technical drawing
